Features:
- Local Mode
- Remote Control mode
- Manual mode
- Constant Speed
- Constant Tension
- Rendering
- Trend data logging for Load / Current / Speed & Pressure
- Integrated hydraulics for Grip/Pivot, Brake & Track balance
- Upper track equipped with Draw wire sensors to fine track level adjustment
- Hydraulic power unit and Valve block with complete HPU controls
- Integrated RIO panel with local operating components
- HMI on the RIO panel for status monitoring locally for the operation team
Sectors:
- Renewable Energy & Oil & Gas
- Communications
Deployment of:
- Power cables & FOC
- Risers, Flexibles, Umbilical & Coil Tubes
Benefits:
- Pivot Track OPEN feature allows for vertical loading of product
without any safety risk
- Pulse input speed control allows the Operator to fine speed
adjustment of the track rotations, this will provide product
safety from operational damages
Control System:
- Control Console placed in an A60 fire rated control Cabin with
clear view glass windows
- HMI c/w Command inputs, Parameter settings, System status
& Alarm monitoring features
- Dashboard for overall view of Equipment operational and
Cable current status
- Complete with proportional speed controls
- Emergency stop function
- Proximity sensors & Load sensors
- Hydraulic pressure sensor
- Linear sensors & Draw wire sensors
